KENWOOD KFC-PS170C SPEAKER

The Kenwood KFC-PS170C is a 6.7" (17cm) 2-way component speaker system with 400W peak power and audiophile-grade crossover—designed for high-performance car audio with precise sound separation and rich detail.

🔊 Key Specifications

• Model: Kenwood KFC-PS170C

• Speaker Type: 2-way component system

• Speaker Size: 170 mm (6.7")

• Peak Power Handling: 400 Watts

• RMS Power Handling: 80 Watts

• Frequency Response: 58 Hz – 22,000 Hz

• Sensitivity: 86 dB/W at 1m

• Nominal Impedance: 4 ohms

• Woofer Cone Material: Wide-etched polypropylene (PP)

• Woofer Magnet: Ferrite

• Tweeter Type: 25 mm soft dome swivel tweeter

• Tweeter Magnet: Neodymium

• Crossover Network: External box with high-quality film capacitors and inductors

• Tweeter High-Pass Filter: -12 dB/octave

• Mounting Depth: 56 mm

• Magnet Weight: 340 g

• Voice Coil Diameter: 25 mm

• Total Weight: ~1.8 kg

📦 Design & Features

• Swivel Tweeter Mounting: Allows directional adjustment after installation

• Convex Shape Cap: Enhances midrange performance

• Diamond Array Cone Pattern: Improves rigidity and reduces distortion

• Audiophile-Grade Crossover: Ensures clean separation of frequencies

• Installation Flexibility: Suitable for doors or rear deck mounting

🎯 Ideal For

• Car audio enthusiasts seeking precise imaging and sound separation

• Systems needing high-output, low-distortion component speakers

• Users upgrading to premium sound quality with custom installation
